cinéwalk

Large projection screen mounted on a self-supporting platform with walkways

The cinéwalk projection screen is stretched over a frame made of black anodized extruded aluminum profiles and fixed on a self-supporting platform composed of lightweight and modular materials. This sturdy structure provides the flexibility to integrate ladders, walkways, or even speakers.

Specially designed for large projection surfaces, each cinéwalk project is customizable, accompanied by technical plans and a thorough site study.


Large fixed
frame screen


From 4m to 100m wide


Self-supporting platform

  • Main Features
    Screen stretched over a black anodized extruded aluminum frame “Postcard” system: the frame and structural elements are hidden behind the canvas Canvas fixed with specially calibrated polyethylene tensioners Screen with rounded corners (R = 100mm) or right angles Projection canvas with 5cm reinforcement and eyelets every 20cm Screen suitable for front and rear projection Compatibility with all projection surfaces Different fixing systems available
  • Specificities
    The screen profiles are easily bendable on site when the curvature does not exceed 5%
  • Options
    Fixed or mobile masking system Screen bending

Technical characteristics

Compatible fabrics

Fabrics
Color
Opacity
Front projection
Rear projection
Perforated version
Micro-perforated version
3D projection
Gain
Weight (gr/m²)
Roll width (cm)
Super Matt
White
-
1.12
450
210
Cinopaque
White
-
-
-
-
1
560
210
Hi White
Pearly
-
1.4 - 1.8
450
-
Spectral 3D
Metalized
-
2.4
500
-
Clarus XC
Metalized
-
1.7 - 2.2
500
-
High Contrast
Grey
-
-
-
0.8
601
240
Infra
Grey
-
-
-
-
-
-
440
230
Retro Grey
grey
-
-
-
-
-
-
440
220
Retro 3D
Grey
-
-
-
-
410
140
Retro Cream
White
-
-
-
-
430
230
Green Screen
Green
-
-
-
-
1
480
170

Inspiration

Would you like to receive a quote?
